Product Parameters
Rated Voltage:600V/DC
Rated Current:200A
Temperature Range:-40~125°C
Cable Range:50mm2
Terminal retention:50kg Min
Bolt grade:8.8
Protection Level: IP67 &IP6K9K
Bolt:M8/M3
Flame Class: UL94 V-0
Material: PA66+Copper Alloy
Positions: 1 Pin
Installation Torque:22±2N.m
Product Application
PDU, Vehicle charaer, Motor controller, Motor, multi-in-one electric control system etc
| Name | P/N | Remarks |
| Low voltage waterproof terminal | GH05-F200-1NNB-L01 |
