Product Parameter
*Rated Voltage： 1000V/AC
*Rated Current： 250A Max
*Temperature Range： -40℃ 〜125℃
*Cable Range： 50mm²/70mm ²
*Protection Level: IP67 & IP6K9K
*Flame Class: UL94 V-0
*Material: PA66+Copper Alloy
*Bolt: M8 /M6
*Terminal retention： 50kg Min
Product Application
PDU, Vehicle charger, Motor controller, Motor, multi-in-one electric control system etc.
