Product Parameter
*Impedance： 50 OHM
*VSWR：1.12(-25 dB)MAX. DC to 3GHz 1.22(-20 dB)MAX.3 to 6GHz 1.67(-12 dB)MAX.6 to 9GHz
*Frequency： DC to 9GHz
*Dielectric withstand voltage： 800VRWS, MIN
*Temperature Range： -40℃〜105℃
*Insertion and dialing times： 25 CYCLES MIN
*Lock retention force： 110N MIN
Product Application
GPS navigation, Radio antenna/ADAS, 4K camera system/In vehicle infotainment system, In vehicle auto drive system/In vehicle electronic instruments, etc
