Product Parameter
*Impedance： 50 OHM
*VSWR：1.4(-15.6dB)MAX. DC to 2GHz 1.5(-13.9dB)MAX.2 to 3GHz
*Frequency： DC to 3GHz
*Dielectric withstand voltage： 800VRWS, MIN
*Insertion and dialing times： 100 CYCLES MIN
*Temperature Range： -40℃〜105℃
*Lock retention force： 110N MIN
Product Application
Wireless antenna, GPS, Satellite broadcasting, RF Bluetooth, IVI information and entertainment system, etc.
