Product Parameter
*Rated Voltage： 500VDC/AC
*Rated Current：
*Signal Terminal 5A
*Power Terminal 13A
*Cable Range： 0.5mm² 〜1.5mm²
*Signal Terminal： 0.35~0.5mm²
*Power Terminal： 0.5〜2.5mm²
*Plug in/out（Times）： 100
*Temperature Range ： -40℃ 〜125℃
*Protection Level: IPX7
*Flame Class: UL94 V-0
*Material: PA66+Metal Alloy
*OD OD of cable： 1.6-2.0mm
Product Application
Industrial controllers, Motor controllers, Automobiles, Marine systems, Integrated circuit control systems, BMS, PDUs and other power energy storage systems.
