Shenzhen GVTong Electronic Technology Co., Ltd. specializes in the production and sales of signal connectors – waterproof, double row, 34/40 core signal connectors – waterproof, double row, 34/40 core signal connectors with low prices and high quality.
Product Parameters
Rated Voltage:500V/DC
Rated Current:3~7A
Plugin/out(Times):50
Temperature Range:-40~125℃
Cable Range:0.3~1.25mm2
Protection Level:IP67&IPX9K
Flame Class: UL94 V-0
Material:PBT+Metal Alloy
Positions:
Double row 34 pin signal connector: 34 pin
Double row 40 pin signal connector: 40 pin
OD of cable:Ф1.4~2.3mm
Product Application
MBMS,BMS,Navigation Application System,On board Unit etc.
| Name | Pin | P/N | Remarks |
| Signal connector-waterproof, double row plug | 34 | GE01-P008-23NNB-Y01 | Unilateral waterproof |
| Signal connector-waterproof, double row socket | 34 | GE01-F003-34NNB-Y01 | Unilateral waterproof |
| Signal connector-waterproof, double row plug | 40 | GE01-P003-40NNB-Y01 | Unilateral waterproof |
| Signal connector-waterproof, double row socket | 40 | GE01-F003-40NNB-Y01 | Unilateral waterproof |
| Signal connector-waterproof, double row terminals | / | S06-0016S-NA-N | Unilateral waterproof |
| Signal connector-waterproof, double row blind plug | / | H13-0001-NA-N | Unilateral waterproof |
