In fields such as industry, automobiles, and ships, the stability and safety of control systems are crucial.However, water vapor and humidity in the environment often become invisible killers that threaten stability.At this time, an excellent waterproof signal connector is particularly important.The waterproof signal connector we present to you is specially designed to solve this pain point.It uses advanced sealing technology to effectively isolate water vapor and ensure stable operation in harsh environments.Whether it is industrial controllers, motor controllers, automobiles, ship systems, integrated circuit control and other application scenarios, choose our waterproof signal connectors to ensure quality and trust.
Product Parameters
Rated Voltage:250V/DC
Rated Current:3~8A
Plugin/out(Times):50
Temperature Range:-40~125°C
Cable Range:0.5~1.5mm2
ProtectionLevel:IP67&IPX9
Flame Class:UL94 V-0
Material:PBT/Metal alloy
Positions:35 Pin
OD ofcable:Ф1.8~2.4mm
Product Application
Motor controller,Motor,BMS,PDU,Air conditioning system
| Name | Pin | P/N | Remarks |
| Signal connector – waterproof, three-row plug | 14 | GE01-P008-35NNB-Y01 | |
| Signal connector – waterproof, three-row straight pin socket | 14 | GVT03-RS013-35-L02 | Unilateral waterproof with nut |
| 14 | GVT03-RS013-35-L03 | With nut unilateral non-waterproof | |
| 14 | GVT03-RS013-35-L04 | Unilateralwaterproof without nut | |
| 14 | GVT03-RS013-35 | Non-nut unilateralnon-waterproof | |
| Signal connector – waterproof, three-row bent pin socket | 14 | GVT03-RA013-35-L02 | Unilateral waterproof with nut |
| 14 | GVT03-RA013-35-L03 | With nut unilateral non-waterproof | |
| 14 | GVT03-RA013-35-L04 | Unilateral waterproof without nut | |
| 14 | GVT03-RA013-35 | Non-nut unilateral non-waterproof | |
| Signal connector – waterproof, three-row reverse bent pin socket | 14 | GVT03-RA013-35-L01 | With nut unilateral non-waterproof |
